ANANDHA FABRICATIONS (CBE) PVT.LTD. Engineers, Fabricators, Consultants & Contractors
An iso 9001 Certified Company
Products
Infrastructure
| Machines | Capacity |
| CNC Plate cutting machine | 1. Messers Make Multitherm Eco 4000 x 16000 with 1 no., of Alfa torch and Omniflow control to cut plates upto 400mm thickness. 2. Messers Make Multitherm eco 4000 x 16000 with Hypertherm Plasma cutting machine to cut SS plates upto 25mm thickness. 3. Bandsaw cutting machine capable to cutting Steel sections upto 200mm is available. |
| Area with EOT | 100,000 Square feet. |
| Hydraulic Presses | a.1000 Ton capacity John Shaw & Sons, England make Hydraulic press. b.600 Ton capacity Riley Bury, England make Hydraulic press. |
| Heat-treatment Furnaces | a.2M X 2M X 2M Gas/Oil fired furnace with Wesman Blower. b.1M X 1M X 1M Gas/Oil fired furnace with Wesman Blower. |
| Rolling Machines | 1.3000mm width x 50mm thick rolling capacity, with pre-pinching and cone formation. Himalaya make, fully hydraulic Machine. 2.2500 width x 25mm thick rolling capacity, W.M.W, Germany make. 3.1600 width x 22mm thick rolling capacity, T.E.E, Bombay make. |
| Turning Machines | 1. Vertical Turret Lathe (VTL) Ø4200mm Swing X 2000 mm height with DRO attachment. 2. Vertical Turret Lathe (VTL) Ø2750mm Swing X 1000 mm height- BETTS make. 3. Horizontal boring machine - 100mm Spindle dia, 1000X1100 between centers. 4. Horizontal Turning Lathe – Ø1600 swing X5000mm long. Swing in gap – Ø2600X600 mm long. 5. Horizontal Turning Lathe – Ø1750X2400mm long. 6. Few smaller lathes. |
| Shaping Machine | 1.Shimato, Japan make-24in stroke. |
| Plano Milling machine | 1.2m x 2m x 4m Plano milling machine (ancillary unit). |
| Drilling | 1.3 nos Radial drilling machines with drilling capacity up to Ø60 mm with DRO attachment. 2.80 mm Capacity ROBAMA German make drilling Machine. |
| Welding Process | 1.SMAW : We have 12 Triyodyne Generators. 2.GTAW : We have 2 TIG Welding Machines. 3.GMAW : We have 3 MIG Welding Machines. 4.FCAW : We have 3 MIG Welding Machines. |
| Material Handling | 1.We have a machine shop bay of size 25’ width x 20’ height x 225’ length having loading capacity of 20 tones. 2.We have a fabrication shop with 2 bays totaling 155’ width x 142’ length x 100’ height with each bay having loading capacity of 40 tones. 3.Mobile crane- ESCORTS make of 14T capacity. 4.3T capacity Fork-lift. |
| Visual & Dimensional Inspection | We have full-fledged inspection facilities at all levels with calibrated measuring instruments. Die-penetrant and Ultrasonic NDT for weld joints is available. Radio-graphic testing (RT) done with 3rd party. |
| Hydrostatic test | 100% hydrostatic test is carried out on finished equipment to check the leakages under hydraulic pressure as per the specification given in drawing. High Pressure Boosting pumps available up to 480 bar. |
| Plasma Cutting | Air Plasma Capacity of cutting up to 50 mm thickness. |
| Power Generation | We have two diesel generators totaling 375 KVA power generation, to power up the factory in-case of a power-shutdown. |
| Grit-blasting and Painting | We have 2 full-fledged grit-blasting and painting booths of over 3000 SfT. We have Graco Airless Spray painting system to speed-up the painting process. |
